- Continuously adjustable regulated DC output voltage: 0~12V, 3A
- Selectable AC output voltage: 2V, 4V, 6V, 12V, 3A output
- DC electronical current protection, AC circuit breaker protection
- Load regulation: 750mV, Line regulation: 20mV, Ripple & noise: 15mV
- Input Voltage: 110~127±10%, 60Hz
Features:
- Both AC and regulated DC output
- DC continuously adjustable
- DC electronical current protection
- AC selectable output voltage
- AC circuit breaker protection
Full Specifications:
- DC Output voltage: 0~12V
- DC Output current: 3A
- Load regulation: 750mV
- Line regulation: 20mV
- Ripple & noise: 15mV
- AC Output voltage: 2V, 4V, 6V, 12V
- AC Output current: 3A
- Input voltage: 110~127±10%, 60Hz
- Dimensions (W x H x D): 220mm x 133mm x 193mm
- Weight: 3kg (6.62 lbs)
Includes:
- Power Supply
- Power Cord
- User's Manual
- 2 Spare Fuses
