17DIP12SS
Regular price
$1.99
Sale price
$1.99
Regular price
Sold out
Unit price
per
Shipping calculated at checkout.

This is a 12-position DIP switch with SPST contacts, raised slide actuators and 24 pins for through-hole mounting. It measures 32.6 mm x 9.6 mm x 7.4 mm, height not including pins. Each position is an independent on/off switch.

Key Features

  • 12 independent SPST switches
  • Raised slide actuators
  • 24-pin through-hole mounting
  • Red color
  • 32.6 x 9.6 x 7.4 mm

Specifications

Positions 12
Switch type Raised slide
Contact form SPST
Pins 24
Mounting Through hole
Dimensions 32.6 x 9.6 x 7.4 mm (height not incl. pins)
Color Red (per title)
SKU 17DIP12SS

What's Included

  • 1 x 12-position DIP switch

Ideal For

Boards that need many configuration bits, such as address or option settings.

Frequently Asked Questions

How do I mount a DIP switch?
It's a through-hole part that fits a standard DIP footprint on a circuit board or a breadboard; solder the pins or plug it into a socket.

What does SPST mean here?
Each slide is a simple on/off switch connecting its own pair of pins.
