- Two level of control for both current and voltage outputs: coarse and fine for ease of use
- Adjustable outputs: 0-30V and 0-5A
- Input voltage: 110V AC and 220V AC switchable
- Ripple noise: CV ≤ 0.5 mV RMS, CC ≤ 3 mA RMS
- LCD reading accuracy: +/-1% for voltage and +/-2% for current
Two level of control for both current and voltage outputs: coarse and fine for ease of use
Adjustable outputs: 0-30V and 0-5A
Input voltage: 110V AC and 220V AC switchable
Line regulation: CV ≤ 0.01% + 1 mV, CC ≤ 0.2% + 1 mA
Load Regulation: CV ≤ 0.01% + 3mV, CC ≤ 0.2% + 3 mA
Ripple noise: CV ≤ 0.5 mV RMS, CC ≤ 3 mA RMS
Protection: constant current and short-circuit protection
LCD reading accuracy: +/-1% for voltage and +/-2% for current
Environment: 0-40C, relative humidity < 90%
Size: 11.5" x 6.5" x 5.5"
Weight: 13 lbs
