- DC Voltage 200mV/2V/20V/200V Accuracy ±(0.5%+2), 600V Accuracy ±(0.8%+2)
- AC Voltage 2V/20V/200V Accuracy ±(0.8%+5), 600V Accuracy ±(1.2%+3)
- Resistance, Capacitance, and Inductance
- CE / ETL / RoHS Certified
- Includes test leads, multi-function socket, battery, and user's manual
? Display 2000 counts
? Auto Power Off
? Non-Contact Voltage Detector
? Transistor hFE 0~1000
? Diode Open Voltage 3.0V
? Continuity Buzzer <50?
? Data Hold
? Display Backlight
? Low Battery Display
Safety Rating: CAT III 600V
Specifications:
DC Voltage 200mV/2V/20V/200V, Resolution: 0.1mV/1mV/10mV/100mV, Accuracy: ±(0.5%+2)
DC Voltage 600V, Resolution: 1V, Accuracy: ±(0.8%+2)
AC Voltage 2V/20V/200V, Resolution: 1mV/10mV/100mV, Accuracy: ±(0.8%+5)
AC Voltage 600V, Resolution: 1V, Accuracy: ±(1.2%+3)
DC Current 200mA, Resolution: 0.1mA, Accuracy: ±(1.5%+1)
DC Current 10A, Resolution: 10mA, Accuracy: ±(2.0%+5)
AC Current 200mA, Resolution: 0.1mA, Accuracy: ±(1.8%+3)
AC Current 10A, Resolution: 10mA, Accuracy: ±(3.0%+7)
Resistance 200?, Resolution: 0.1?, Accuracy: ±(0.8%+5)
Resistance 2k?/20k?/200k?/2M?, Resolution: 1?/10?/100?/1k?, Accuracy ±(0.8%+5)
Resistance 20M?, Resolution: 10k?, Accuracy ±(1.0%+2)
Resistance 200M?, Resolution: 0.1M?, Accuracy ±(5.0%+5)
Capacitance 20nF/200nF/2?F, Resolution: 0.01nF/0.1nF/0.001?F, Accuracy: ±(4.0%+5)
Capacitance 200?F, Resolution: 0.1?F, Accuracy: ±(5.0%+5)
Inductance 20mH/200mH/2H/20H, Resolution: 0.01mH/0.1mH/1mH/10mH, Accuracy: ±(3.0%+5)
MAX. Voltage between terminals and earth ground: 600V AC rms or 600V DC
Fuse Protection: mA: fuse(FF400mA/1000V) and A: fuse(FF10A/600V)
Sample Rate: 3 times/sec for digital data
Display: 3 1/2 digits LCD display
Over Range indicator
Low battery indicator
Includes test leads, multi-function socket, battery, and user's manual
Product Weight: 1 LB
