Bench Digital Multimeter True-RMS with RS232 Interface, Backlit 3999 Count LCD

01DMM9803R
$195.00
$195.00
Sold out
Shipping calculated at checkout.
  • 3-3/4 (3999) count) large LCD display with back light, Bar graph display - 42 segment
  • DC Volts - 1,000 VDC 5 ranges, .3% accuracy, AC Volts - True RMS, 750VAC 4 ranges, AC (true RMS)/DC Current - 10 amp 4 ranges
  • True RMS for AC voltage/current, Resistance - 40M 6 ranges, Capacitance - 40uF 5 ranges, Frequency counter up to 600KHz, accuracy 0.1%, Sensitivity: 100mV up to 20KHz, 500mV 20-600KHz, Adapted range: Display 10 counts per 1mV DC
  • RS232C standard interface - software included, Runs on AC or DC (either one 9V or 6 AA batteries), Features Pop-up stand and carry strap
  • Data hold, min/max relative measuring, storage data
• 3-3/4 (3999) count) large LCD display with back light
• Auto and manual range
• True RMS for AC voltage/current
• RS232C standard interface - software included.
• Data hold, min/max relative measuring, storage data display/recall, continuity and diode test
• DC Volts - 1,000 VDC 5 ranges, .3% accuracy.
• AC Volts - True RMS, 750VAC 4 ranges.
• AC (true RMS)/DC Current - 10 amp 4 ranges.
• Resistance - 40M 6 ranges.
• Capacitance - 40uF 5 ranges.
• Frequency counter up to 600KHz, accuracy 0.1%
• Sensitivity: 100mV up to 20KHz, 500mV 20-600KHz
• Adapted range: Display 10 counts per 1mV DC
• Optional Power Feature - Runs on AC or DC (either one 9V or 6 AA batteries).
• Batteries not included.
• Pop-up stand and carry strap.

Specifications:
DCV: 0-400m-4-40-400-1kV±0.3%
ACV: 0-4-40±0.8%-400-750V±1.2%(40Hz-1kHz)
DCA: 0-4m-40m-400m±0.8%-10A±2.0%(20A for 30 Sec.)
ACA: 0-4m-40m-400m±1.5%-10A±2.0%(20A for 30 Sec.)
R: 0-400-4k-40k-400k±0.5%-4M±1.0%-40Mohm±1.5%
CAP: 0-4n-40n-400n-4u-20±2.0%-40uF±5.0%
Frequency: 0-100-1k-10k-100k-1MHz±0.1%
Audible continuity: <50ohm
Diode Test: 0.6mA,0.3V

Test leads, Power cord, RS232C cable, software and carrying strap are included.

Product Dimensions (L x W x H): 305 x 274 x 112 MM

Product Weight: 5.95 LB
